MD75 Encoder Module with OLED Screen Display
|
Module model： |
MD75 series |
|
| Applications： |
Washing machines and other household appliances; |
|
| Product Features: |
A multi-functional module integrated with OLED, digital LED display and rotary encoder. |
|
| Main Specifications: |
Dimension: 77mm; |
ONE、MECHANICAL CHARACTERISTIC
1. Rotational torque: 60±20mN.m
2. Total ratational angle: 360°
3. Number of detent: 14
TWO、ELECTRICAL CHARACTERISTIC
1. Insulation Resistance: 100M?
2. Dielectric Voltage: 1 Minute at AC 300V
3. Pulses: 14
THREE、ENDURANCE CHARACTERISTIC
1. Rotational life: 30,000 cycles Min
Note: In this catalog, if some parameters or drawings are different from the "Approval sheet", it's subject to the "Approval sheet".
